Condura Split Type Inverter
Condura Split Type Inverter
Why it's ProtecTibay?
All Condura air conditioners are equipped with their own unique ProtecTibay System to ensure a longer lifespan.
Automatically detects problems for quick troubleshooting
Enable automatic cleaning to prevent molds and remove dust
Enjoy continuous cooling even if a sensor issue arises
For peak efficiency and long-lasting performance
For anti-rust and powder-painted metal for robust built
Ensuring reliable performance even in harsh environments
Get a complete view of the product's specifications, from physical dimensions to material quality and special features.
Other features
Durable
Energy Efficient
Comfort & Convenience
Air Flow & Air Quality
| Power supply |
V- Ph-Hz |
230V_1Ph_60HZ |
| Cooling Capacity |
Kj/ hr |
9,500 (3,850- 10,350) |
| Cooling Input | W |
824 (320 -1,184) |
| Cooling Current | A |
6.3 (2.45- 9.05) |
| Cooling CSPF | - | 4.90 |
| DOE Energy Label | - | 5 Star |
| Rated Power Input | W | 1,900 |
| Rated Current | A | 13 |
| Indoor Fan Motor Speed |
r/min Hi/Mi/Lo |
1150/950/750 |
| Indoor Air Flow |
m3/h Hi/Mi/Lo |
486/390/280 |
| Indoor Noise Level |
dB(A) Hi/Mi/Lo |
39/33/27 |
| Indoor Unit Dimension | mm
W*D*H |
715x194x285 |
| Indoor Unit Packing | mm
W*D*H |
780x270x365 |
|
Indoor Unit Net/Gross weight |
kg |
7.2/9.3 |
| Indoor Unit Stacking Height | - | 8 |
| Outdoor Fan Motor Speed | r/min |
800/600 |
| Outdoor Air Flow | m3/h | 1800 |
| Outdoor Noise Level | dB(A) | 53.5 |
| Outdoor Unit Dimension | mm
W*D*H |
720x270x495 |
| Outdoor Unit Packing | mm
W*D*H |
835x300x540 |
| Outdoor Unit Net/Gross Weight | kg |
18.8/20.7 |
| Outdoor Unit Stacking Height | - | 4 |
| Refrigerant Type | kg | R32/0.35 |
| Refrigerant Piping Liquid Side/Gas Side | mm (inch) |
6.35mm(1/4in)/ 9.52mm(3/8in) |
| Refrigerant Piping Max. Pipe Length | m | 25 |
| Refrigerant Piping Max. difference in level | m | 10 |
| Power supply |
V- Ph-Hz |
230V_1Ph_60HZ |
| Cooling Capacity |
Kj/ hr |
12,650 (4,100- 13,200) |
| Cooling Input | W |
1,230 (150- 1,250) |
| Cooling Current | A |
8.7 (1.6- 8.0) |
| Cooling CSPF | - | 4.83 |
| DOE Energy Label | - | 5 Star |
| Rated Power Input | W | 2,200 |
| Rated Current | A | 11 |
| Indoor Fan Motor Speed |
r/min Hi/Mi/Lo |
1180/950/750 |
| Indoor Air Flow |
m3/h Hi/Mi/Lo |
580/450/310 |
| Indoor Noise Level |
dB(A) Hi/Mi/Lo |
40.5/34/26.5 |
| Indoor Unit Dimension | mm
W*D*H |
805x194x285 |
| Indoor Unit Packing | mm
W*D*H |
870x270x365 |
|
Indoor Unit Net/Gross weight |
kg |
7.7/9.8 |
| Indoor Unit Stacking Height | - | 8 |
| Outdoor Fan Motor Speed | r/min |
900/800 |
| Outdoor Air Flow | m3/h | 1800 |
| Outdoor Noise Level | dB(A) | 54 |
| Outdoor Unit Dimension | mm
W*D*H |
720x270x495 |
| Outdoor Unit Packing | mm
W*D*H |
835x300x540 |
| Outdoor Unit Net/Gross Weight | kg |
19.9/21.8 |
| Outdoor Unit Stacking Height | - | 4 |
| Refrigerant Type | kg | R32/0.4 |
| Refrigerant Piping Liquid Side/Gas Side | mm (inch) |
6.35mm(1/4in)/ 12.7mm(1/2in) |
| Refrigerant Piping Max. Pipe Length | m | 25 |
| Refrigerant Piping Max. difference in level | m | 10 |
| Power supply |
V- Ph-Hz |
230V_1Ph_60HZ |
| Cooling Capacity |
Kj/ hr |
19,000 (7,280- 19,500) |
| Cooling Input | W |
1,850 (190- 2,000) |
| Cooling Current | A |
8 (1.5- 8.7) |
| Cooling CSPF | - | 4.76 |
| DOE Energy Label | - | 5 Star |
| Rated Power Input | W | 2,950 |
| Rated Current | A | 13.5 |
| Indoor Fan Motor Speed |
r/min Hi/Mi/Lo |
1200/1000/800 |
| Indoor Air Flow |
m3/h Hi/Mi/Lo |
800/660/500 |
| Indoor Noise Level |
dB(A) Hi/Mi/Lo |
44.5/38.5/31 |
| Indoor Unit Dimension | mm
W*D*H |
957x213x302 |
| Indoor Unit Packing | mm
W*D*H |
1035x295x385 |
|
Indoor Unit Net/Gross weight |
kg |
10.4/13.2 |
| Indoor Unit Stacking Height | - | 8 |
| Outdoor Fan Motor Speed | r/min |
810/600 |
| Outdoor Air Flow | m3/h | 2100 |
| Outdoor Noise Level | dB(A) | 54 |
| Outdoor Unit Dimension | mm
W*D*H |
765x303x555 |
| Outdoor Unit Packing | mm
W*D*H |
887x337x610 |
| Outdoor Unit Net/Gross Weight | kg |
24.4/26.7 |
| Outdoor Unit Stacking Height | - | 4 |
| Refrigerant Type | kg | R32/0.6 |
| Refrigerant Piping Liquid Side/Gas Side | mm (inch) |
6.35mm(1/4in)/ 12.7mm(1/2in) |
| Refrigerant Piping Max. Pipe Length | m | 30 |
| Refrigerant Piping Max. difference in level | m | 20 |
| Power supply |
V- Ph-Hz |
230V_1Ph_60HZ |
| Cooling Capacity |
Kj/ hr |
23,400 (2,520- 24,000) |
| Cooling Input | W |
2,250 (235- 2,256) |
| Cooling Current | A |
10.4 (1.8- 11.3) |
| Cooling CSPF | - | 4.25 |
| DOE Energy Label | - | 5 Star |
| Rated Power Input | W | 3,000 |
| Rated Current | A | 14.5 |
| Indoor Fan Motor Speed |
r/min Hi/Mi/Lo |
1200/1000/850 |
| Indoor Air Flow |
m3/h Hi/Mi/Lo |
960/750/600 |
| Indoor Noise Level |
dB(A) Hi/Mi/Lo |
47/41/37 |
| Indoor Unit Dimension | mm
W*D*H |
1040x220x327 |
| Indoor Unit Packing | mm
W*D*H |
1120x405x315 |
Indoor Unit Net/Gross weight |
kg |
13.0/16.5 |
| Indoor Unit Stacking Height | - | 8 |
| Outdoor Fan Motor Speed | r/min |
900/600 |
| Outdoor Air Flow | m3/h | 2300 |
| Outdoor Noise Level | dB(A) | 57 |
| Outdoor Unit Dimension | mm
W*D*H |
805x330x554 |
| Outdoor Unit Packing | mm
W*D*H |
915x370x615 |
| Outdoor Unit Net/Gross Weight | kg |
29/31.5 |
| Outdoor Unit Stacking Height | - | 3 |
| Refrigerant Type | kg | R32/0.78 |
| Refrigerant Piping Liquid Side/Gas Side | mm (inch) |
6.35mm(1/4in)/ 12.7mm(1/2in) |
| Refrigerant Piping Max. Pipe Length | m | 30 |
| Refrigerant Piping Max. difference in level | m | 20 |
